Bore Size & Shape(in)(mm):
0.750 Round
Center Line To End Of Hub (in):
2.500
End Of Hub To Set Screw (in):
0.500
End Yoke Part Number:
10-0423
Keyway Width (in)(mm):
0.250
Set Screw Thread Size (in)(mm):
3/8-16 UNC 2B
Yoke 1 Bore Size & Shape (in)(mm):
0.750 Round
Yoke 1 Center Line To End Of Hub (in):
2.500
Yoke 1 End Of Hub To Set Screw (in):
0.500
Yoke 1 Keyway Location:
Gap
Yoke 1 Keyway Width (in)(mm):
0.251
Yoke 1 Set Screw Location:
Gap
Yoke 1 Set Screw Thread Size (in)(mm):
3/8-16 UNC 2B
Yoke 2 Bore Size & Shape (in)(mm):
0.750 Round
Yoke 2 Center Line To End Of Hub (in):
2.500
Yoke 2 End Of Hub To Set Screw (in):
0.500
Yoke 2 Keyway Location:
Gap
Yoke 2 Keyway Width (in)(mm):
0.251
Yoke 2 Set Screw Location:
Gap
Yoke 2 Set Screw Thread Size (in)(mm):
3/8-16 UNC 2B
