N4-1-1133-9 Driveshaft Companion Flange

(No reviews yet) Write a Review

Part Number

N4-1-1133-9

Bolt Circle (in):

4.750

Bore Dia. (in):

2.375

Driveline Series:

1480-1550

Flange Type:

Standard

Hole Dia./Thread Size (in)(mm):

0.516

Keyway (max):

0.628

Keyway Width (in)(mm):

0.625

Number Of Bolt Holes:

4

Outside Diameter (in):

5.875

Overall Length (in):

2.500

Pilot Diameter (in)(mm):

3.750

Set Screw Hole Size (in):

1/2-13

N4-1-1133-9 Driveshaft Companion Flange
